Balluff – BOS0087 BOS 26K-NA-1LQP-S4-C – Retroreflective sensors

MPN: BOS0087 · Brand: Balluff

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Retroreflective sensors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can BOS0087 be shipped?

BOS0087 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BOS0087 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BOS0087 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BOS0087, subject to availability and destination.

Balluff BOS0087 (BOS 26K-NA-1LQP-S4-C) — Retroreflective sensor. Series: 26K; Dimension: 17 x 50 x 50 mm; Interface: NPN: normally open (NO) NPN: normally closed (NC); Principle of optical operation: Retroreflective sensor; Special optical feature: Coaxial optics. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Type designation	BOS 26K-NA-1LQP-S4-C
Product group	Retroreflective sensors

Key features

Series	26K
Dimension	17 x 50 x 50 mm
Interface	NPN: normally open (NO) NPN: normally closed (NC)
Principle of operation	Photoelectric sensor
Principle of optical operation	Retroreflective sensor
Special optical feature	Coaxial optics
Beam characteristic	Collimated
Light type	Laser red light
Light spot size	Ø 20 mm at 20 m
Range	0...25 m
Connection	Connector, M12x1-Male, 4-pin
Housing material	ABS
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	cULus CE WEEE
