Balluff – BOD0002 BOD 26K-LA01-S4-C – Photoelectric distance sensors
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Photoelectric distance sensors |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
When can BOD0002 be shipped?
BOD0002 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up BOD0002 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for BOD0002 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BOD0002, subject to availability and destination.
Balluff BOD0002 (BOD 26K-LA01-S4-C) — Photoelectric distance sensor. Series: 26K; Dimension: 17 x 50 x 50 mm; Interface: Analog, voltage: 0…10 V linear increasing; Principle of optical operation: Triangulation; Beam characteristic: Divergent. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Active |
| Type designation | BOD 26K-LA01-S4-C |
| Product group | Photoelectric distance sensors |
Key features
| Series | 26K |
| Dimension | 17 x 50 x 50 mm |
| Interface | Analog, voltage: 0…10 V linear increasing |
| Principle of operation | Photoelectric distance sensor |
| Principle of optical operation | Triangulation |
| Beam characteristic | Divergent |
| Light type | Laser red light |
| Light spot size | Ø 0.8 mm at 65 mm |
| Range | 45...85 mm |
| Accuracy | ±1 % FS |
| Resolution | ≤ 80 µm |
| Connection | Connector, M12x1-Male, 4-pin |
| Housing material | ABS |
| Operating voltage Ub | 18...28 VDC |
| Approval/Conformity | CE cULus WEEE |
Classifications
| ECLASS 14.0 | 27-27-09-16 |
| ETIM 9.0 | EC001825 |
| UNSPSC 11 | 39121528 |
