Balluff BNS03WJ (BNS 819-B04-R10-46-12-FC-S80S) — Mechanical multiple position limit switches. Dimension: 72 x 72 x 49 mm; Housing material: Aluminium, Anodized; Number of switching positions: 4x Roller; Version: Snap contact; Operating principle: 1-4. Switch position: Mechanical. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.
| Lifecycle | Active |
| Type designation | BNS 819-B04-R10-46-12-FC-S80S |
| Product group | Mechanical multiple position limit switches |
| Dimension | 72 x 72 x 49 mm |
| Housing material | Aluminium, Anodized |
| Number of switching positions | 4x Roller |
| Version | Snap contact |
| Operating principle | 1-4. Switch position: Mechanical |
| Continuous current | 1-4. Switch position: 4 A |
| Rated operating voltage Ue | 1-4. Switch position: 24 V DC |
| Installation | Vertical |
| Approach direction | longitudinal, parallel to attachment surface |
| Approach speed | 1-4. Switch position: 60 m/min |
| Switch position spacing | 10 mm |
| Connection type | 1. Switch position: Connector |
| Ambient temperature | -5...85 °C |
| IP rating | IP67 |
| Approval/Conformity | CE WEEE |
| ECLASS 14.0 | 27-27-06-02 |
| ETIM 9.0 | EC001829 |
| UNSPSC 11 | 41111900 |
No matching specifications
BNS03WJ is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Yes — mention it when you request a quote for BNS03WJ and we'll include express shipping options in our reply.
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BNS03WJ, subject to availability and destination.
