Balluff – BHS002N BES 516-300-S241-D-PU-00,80 – Pressure-rated inductive sensors
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Pressure-rated inductive sensors |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
When can BHS002N be shipped?
BHS002N is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up BHS002N in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for BHS002N and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BHS002N, subject to availability and destination.
Balluff BHS002N (BES 516-300-S241-D-PU-00,80) — Pressure-rated inductive sensor. Dimension: Ø 12 x 47 mm; Style Housing: M12x1; Installation: for flush mounting; Range: 1.5 mm; Switching output: PNP normally closed (NC). PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Active |
| Type designation | BES 516-300-S241-D-PU-00,80 |
| Product group | Pressure-rated inductive sensors |
Key features
| Dimension | Ø 12 x 47 mm |
| Style Housing | M12x1 |
| Installation | for flush mounting |
| Range | 1.5 mm |
| Switching output | PNP normally closed (NC) |
| Switching frequency | 2000 Hz |
| Housing material | Stainless steel |
| Material sensing surface | EP |
| Connection | Cable, 0.80 m, PUR |
| Operating voltage Ub | 10...30 VDC |
| Ambient temperature | -25...80 °C |
| Pressure rating max. | 500 bar |
| IP rating | IP68 |
| Approval/Conformity | cULus CE EAC |
Classifications
| ECLASS 14.0 | 27-27-40-01 |
| ETIM 9.0 | EC002714 |
| UNSPSC 11 | 41111926 |
