Balluff – BES01UP BES Q08ZE-PSC20B-BP06 – Inductive proximity switches and proximity sensors

MPN: BES01UP · Brand: Balluff

Price on request

Discontinued by Balluff — we can still source the original BES01UP (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Inductive proximity switches and proximity sensors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Recommended replacement	BES01TT, BES01TR
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the BES01UP now that it is discontinued?

Yes. Balluff has discontinued the BES01UP, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Balluff names the BES01TT as its successor — we can quote both.

When can BES01UP be shipped?

BES01UP is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BES01UP in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BES01UP and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BES01UP, subject to availability and destination.

Balluff BES01UP (BES Q08ZE-PSC20B-BP06) — Inductive proximity switches and proximity sensor. Dimension: 40 x 8 x 8 mm; Style Housing: 8x8; Installation: for flush mounting; Range: 2 mm; Switching output: PNP normally open (NO). Discontinued by Balluff; Balluff names BES01TT, BES01TR as alternative. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued by Balluff
Type designation	BES Q08ZE-PSC20B-BP06
Product group	Inductive proximity switches and proximity sensors
Balluff alternatives	BES01TT, BES01TR

Key features

Dimension	40 x 8 x 8 mm
Style Housing	8x8
Installation	for flush mounting
Range	2 mm
Switching output	PNP normally open (NO)
Switching frequency	3000 Hz
Housing material	Zinc, Die casting
Material sensing surface	PBT
Connection	Cable, 6.00 m, PUR
Operating voltage Ub	10...30 VDC
Ambient temperature	-25...70 °C
IP rating	IP67
Approval/Conformity	cULus CE EAC
Principle of operation	Inductive sensor
