Balluff – BES01U4 BES Q08ZC-PSC30B-S49G – Inductive proximity switches and proximity sensors

MPN: BES01U4 · Brand: Balluff

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Inductive proximity switches and proximity sensors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can BES01U4 be shipped?

BES01U4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BES01U4 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BES01U4 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BES01U4, subject to availability and destination.

Balluff BES01U4 (BES Q08ZC-PSC30B-S49G) — Inductive proximity switches and proximity sensor. Dimension: 59 x 8 x 8 mm; Style Housing: 8x8; Installation: for flush mounting; Range: 3 mm; Switching output: PNP normally open (NO). PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Type designation	BES Q08ZC-PSC30B-S49G
Product group	Inductive proximity switches and proximity sensors

Key features

Dimension	59 x 8 x 8 mm
Style Housing	8x8
Installation	for flush mounting
Range	3 mm
Switching output	PNP normally open (NO)
Switching frequency	1000 Hz
Housing material	Zinc, Die casting
Material sensing surface	PBT
Connection	Connector, M8x1-Male, 3-pin
Operating voltage Ub	10...30 VDC
Ambient temperature	-25...70 °C
IP rating	IP67
Approval/Conformity	CE UKCA cULus WEEE
Principle of operation	Inductive sensor
