Allen-Bradley – 800T-3TGG 30mm Push Button Station 800T PB

MPN: 800T-3TGG · Brand: Rockwell Automation / Allen-Bradley

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Back of Panel Components, 30 mm
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 800T-3TGG be shipped?

800T-3TGG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 800T-3TGG in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 800T-3TGG and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 800T-3TGG, subject to availability and destination.

Allen-Bradley 800T-3TGG — 30mm Push Button Station 800T PB. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Repair options available	No

Specifications

Number of Push-Buttons	3 Push Buttons
Type	30mm Push Button Station
Bottom button option	Red STOP button
Conduit entry	3/4 in, 14 NPT
Contact block configuration	1-NO 1-NC standard contacts
Contact block electrical design life (cycles, at max. load)	1000000
Contact block operational voltage, max	600V AC @ 600V DC
Contact block termination tightening torque	6 - 8 in-lb / 0.7 - 0.9 N-m
Contact block termination wire range	14 - 18 AWG (x2)
Contact block thermal current rating	10 A
Contact block utilization category (AC)	A600, AC-15
Contact block utilization category (DC)	Q600, DC-13
Enclosure compatibility (NEMA type)	1, 4, 12, 13
Enclosure material	Die Cast Aluminum
Enclosure mounting	Surface mount
Hazardous location rating	false
Humidity	50 %
Indicating lights	None
Number of push buttons	3
Operating temperature	-25 °C
Operator cap type	Flush head
Operator legend text	START - JOG - STOP
Operator mechanical design life (cycles, min.)	1.0E7
Operator mounting hole dimension	30.5 mm
Operator special function	Mushroom head STOP button
Shock	25 G (contact fragility)/100 G (no damage)
Station type	Push button
Storage temperature	-40 °C
Termination style	Screw
Vibration	10 G maximum
