Allen-Bradley – 800H-GR2D1R 30mm Momentary Push Button 800H PB

MPN: 800H-GR2D1R · Brand: Rockwell Automation / Allen-Bradley

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	800T/H Operators
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 800H-GR2D1R be shipped?

800H-GR2D1R is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 800H-GR2D1R in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 800H-GR2D1R and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 800H-GR2D1R, subject to availability and destination.

Allen-Bradley 800H-GR2D1R — 30mm Momentary Push Button 800H PB. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Repair options available	No

Specifications

Type	30mm Momentary Push Button
Contact block configuration	1 NO, Logic Reed contact block (800T-XD1R)
Contact block electrical design life (cycles, at max. load)	200000
Contact block operational voltage, max	150V AC @ 30V DC
Contact block termination tightening torque	6 - 8 in-lb / 0.7 - 0.9 N-m
Contact block termination wire range	14 - 18 AWG (x2)
Enclosure compatibility (NEMA type)	1, 4, 4X, 12, 13
Hazardous location rating	Class I, div. 2
Hole diameter	30.5 mm
Humidity	50 %
Operating temperature	-25 °C
Operator cap/button material	Plastic
Operator cap/button shape	Round
Operator cap color	Black
Operator cap type	Guarded head
Operator construction/material	Plastic
Operator function	Momentary contact
Operator mechanical design life (cycles, min.)	1.0E7
Operator type	Push button
Shock	25 G (contact fragility)/100 G (no damage)
Storage temperature	-40 °C
Suitable for illumination	false
Terminations with finger safe covers	false
Type of electric connection	Screw connection
