What is the Allen-Bradley 800FM-LSL33PQ3GX40?

Allen-Bradley 800FM-LSL33PQ3GX40 — 22mm Selector Switch 800F PB. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

LifecycleActive
Repair options availableNo

Specifications

Contact block configuration4 NO
Contact block durability1.0E7
Contact block mounting styleLatch
Contact block operational voltage, max600V (A600, Q600) - screw termination
Contact block termination tightening torque6 - 8 in-lb / 0.7 - 0.9 N-m
Contact block termination wire range#18...12 AWG (0.75...2.5 mm²)
Contact block thermal current rating10 A
Contact block typeStandard
Contact block utilization category (AC)A600, AC 15 - screw termination
Contact block utilization category (DC)Q600, DC-13 - screw termination
Enclosure compatibilityIP66, Type 4/13 (Round metal operator)
Hazardous location ratingfalse
Hole diameter22.5 mm
Humidity≤95% RH from 25...60 °C (77...140 °F)
Illumination lamp typeLED
Illumination module input voltage24V AC/DC
Illumination module mounting styleLatch
Illumination module termination tightening torque6 - 8 in-lb / 0.7 - 0.9 N-m
Illumination module termination wire range#18...12 AWG (0.75...2.5 mm²)
Illumination module typeLED
Lamp typeGreen LED
Latch materialPlastic
Material front ringMetal
Number of contacts as normally open contact4
Number of switch positions3
Operating temperature-25 °C
Operator cap/button materialMetal
Operator cap colorGreen
Operator construction/materialMetal
Operator functionSpring return from left, 3 position
Operator mechanical design life (cycles, min.)1000000
Operator typeIlluminated selector switch
PackagingStandard pack (1 per package)
Power module typeIntegrated LED (screwless)
Shock100 G
Spring-returntrue
Storage temperature-40 °C
Suitable for illuminationtrue
Supply voltage24 V
Switching function latchingfalse
Switch orientationStandard
Termination styleScrew
Type of control elementShort thumb-grip
Type of electric connectionScrew connection
Vibration10 G
With light sourcetrue
