Allen-Bradley 512-BCB-A2E-3-4GR-901

NEMA Combination Starter Disconnect

MPN
512-BCB-A2E-3-4GR-901
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Rockwell Automation / Allen-Bradley parts? We buy surplus →

What is the Allen-Bradley 512-BCB-A2E-3-4GR-901?

Allen-Bradley 512-BCB-A2E-3-4GR-901 — NEMA Combination Starter Disconnect. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

LifecycleActive
Repair options availableNo

Specifications

Altitude10000 ft before derating
Auxiliary contact materialSilver
Circuit closing inrush current peak including offset, max288 A
Coil operating limits85...110%
Continuous current27 A
Coordination class according to IEC 60947-4-3Class 2
Corrosion-resistanceAll metal parts are treated for corrosion-resistance
Degree of protection (NEMA)4X
Depth8.25 mm
Enclosure typeNEMA 4/4X Stainless Steel
External reset possibletrue
Factory installed modelsPilot lights, incandescent illumination option, green color lens for first pilot light, red color lens for s pilot light
Fuse clipsNo fuse clips
Heat dissipation5.9 W
Height27.5 mm
Hp rating10 Hp
Load voltage460V
Material housingStainless Steel
Mechanical life operations1.0E7
NEMA sizeSize 1
Number of auxiliary contacts, max8
Number of indicator lights2
Operating positionVertical
Operating temperature-25 °C
Operating time, drop-out14 ms
Operating time, pick-up22 ms
Operating volt amperes burdenSealed: 29VA, 60 Hz coils
Overload relayE1 plus, manual reset, Class 20, full load current adjustment range 1.6...5.0 A
Overload release current setting1.6 A
Power contact materialSilver Alloy
Rated control supply voltage at AC 50 Hz480 V
Rated control supply voltage at AC 60 Hz480 V
Release classCLASS 20
Required torque on power terminal wire clamps and pressure connectors or lugs20 in-lb
Suitable for emergency stoptrue
Temperature compensated overload protectiontrue
Type of electrical connection for auxiliary- and control current circuitScrew connection
Type of electrical connection of main circuitScrew connection
Type of motor starterDirect online starter (DOL)
Type of power terminalSaddle or wire clA
Voltage type for actuatingAC
Weight40 lb
Width10.5 mm
Wire sizeFor power terminals: 14...8 AWG
With fusefalse
With short-circuit releasefalse
With transformerfalse

512-BCB-A2E-3-4GR-901: frequently asked questions

When can 512-BCB-A2E-3-4GR-901 be shipped?

512-BCB-A2E-3-4GR-901 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 512-BCB-A2E-3-4GR-901 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 512-BCB-A2E-3-4GR-901 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 512-BCB-A2E-3-4GR-901, subject to availability and destination.
