Allen-Bradley – 2711P-B6M5A8 PanelView Plus 6 6 Gray/Touch AC RS232

MPN: 2711P-B6M5A8 · Brand: Rockwell Automation / Allen-Bradley

Price on request

Discontinued by Rockwell Automation / Allen-Bradley — we can still source the original 2711P-B6M5A8 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	2711P PanelView Plus 7 Graphic Terminals
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the 2711P-B6M5A8 now that it is discontinued?

Yes. Rockwell Automation / Allen-Bradley has discontinued the 2711P-B6M5A8, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 2711P-B6M5A8 be shipped?

2711P-B6M5A8 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 2711P-B6M5A8 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 2711P-B6M5A8 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 2711P-B6M5A8, subject to availability and destination.

Allen-Bradley 2711P-B6M5A8 — PanelView Plus 6 6 Gray/Touch AC RS232. Discontinued by Rockwell Automation on September 30, 2021. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued
Discontinued date	September 30, 2021
Replacement category (Rockwell)	No planned RA replacement
Repair options available	Yes

Specifications

Image Aspect Ratio	Standard (4:3)
Type of Display	TFT Grayscale
Additional software components, loadable	true
Altitude, operating	2000 m
Backlight	White LED, Not replaceable, 25,000 hr minimum at 25 °C (77 °F)
Battery (real-time clock)	Battery-backed clock timestA critical data, accuracy is ±2 min per month, Battery life: 4 yr min at 25 °C (77 °F), Field-replaceable: cat. no. 2711P-RY2032 or equivalent CR2032 coin-cell lithium battery
Brightness	440 cdb/m²
Built-in depth	98 mm
Communication ports	RS-232, 1 USB host, 1 USB device port (catalog numbers with the number 5, for exAle, 2711P-B4C5D8), Ethernet (10/100 Mbps, Auto-MDI/MDI-X), RS-232, 1 USB host, 1 USB device port (catalog numbers with the number 20, for exAle, 2711P-B4C20D8)
Cutout dimensions	Keypad: 142 x 241 mm (5.61 x 9.50 in), Touch: 123 x 156 mm (4.86 x 6.15 in)
Degree of protection (IP), front side	IP66
Degree of protection (NEMA), front side	4X
Dimensions, approx	Keypad: 167 x 266 x 68 mm, Touch: 152 x 185 x 68 mm
Display area	115 x 86 mm (4.5 x 3.4 in)
Display size	5.7 in
Display type	Grayscale, thin-film transistor (TFT) with liquid crystal display (LCD)
Enclosure rating	NEMA Type 12, 13, 4X (Indoor use only), IP54, IP65
External storage	Secure Digital (SD) card, cat. no.1784-SDx, supported by hot-swappable SD card slot, USB flash drive that is supported by high-speed, hot-swappable, 2.0 USB host port
FactoryTalk view software	FactoryTalk view machine edition station runtime, version 6.0 or later, is preloaded and activated on each terminal, Single license support for FactoryTalk viewpoint software, version 1.2 or later, gives remote users access to a terminal’s displays via st
Heat dissipation	84 btu/hr
Height of the front	185 mm
High memory capacity	512 MB RAM, 512 MB nonvolatile memory, (approx. 79 MB free user memory)
Input voltage	100...240V AC @ 50...60Hz
IO link master	false
Keypad description	Stainless-steel membrane, Numeric, navigation and function keys, Actuation: 1 mon presses, Operating force: 340 g
Keypad function keys	10 function keys (F1...F10)
List of degrees of protection (IP)	IP54, IP65
List of degrees of protection (NEMA)	4X, 12, 13
Network interface	For optional Ethernet, DH+, DH-485, or ControlNet communication module
Nonoperating temperature	-25 °C
Number of buttons with LED	0
Number of function buttons, programmable	0
Number of grey-scales/blue-scales of display	1
Number of HW-interfaces industrial Ethernet	0
Number of HW-interfaces other	0
Number of HW-interfaces parallel	0
Number of HW-interfaces RS-232	1
Number of HW-interfaces RS-422	0
Number of HW-interfaces RS-485	0
Number of HW-interfaces serial TTY	0
Number of HW-interfaces USB	2
Number of HW-interfaces Wireless	0
Number of interfaces PROFINET	0
Number of online languages	20
Number of password levels	2
Number of pixels, horizontal	320
Number of pixels, vertical	240
Number of system buttons	0
Operating system	Windows CE 6.0 operating system with or without extended features and microsoft office file viewers
Operating temperature	0 °C
Operator input	Keypad and touch
Power consumption	160VA max, 65VA typical
Power input	AC
Process default value (input) possible	true
Process value representation (output) possible	true
Radio standard Bluetooth	false
Radio standard GPRS	false
Radio standard GSM	false
Radio standard UMTS	false
Radio standard Wi-Fi 802.11	false
Rail mounting possible	false
Relative humidity	5...95% noncondensing (5...90% noncondensing only for low reflective terminal, catalog number 2711P-B4C20D8-LR)
Reset and default switches	Provide easy access to diagnostic and repair ops
Resolution	320 x 240, 16-levels gray
Screen diagonal	5.7 in
Secure Digital (SD) card slot	Hot-swappable card slot supports 1784-SDx and 1784-SDHCx SD cards for transferring files, upgrading firmware, or logging data
Shock	Operating: 15 G @ 11 ms, Nonoperating: 30 G @ 11 ms
Software	FactoryTalk view machine edition software, version 6.10 or later, FactoryTalk viewpoint software is not supported on the 400 and 600 terminals
Suitable for safety functions	false
Supply voltage AC 50 Hz	100 V
Supply voltage AC 60 Hz	100 V
Supporting protocol for ASI	false
Supporting protocol for AS-Interface Safety at Work	false
Supporting protocol for CAN	false
Supporting protocol for Data-Highway	false
Supporting protocol for DeviceNet	false
Supporting protocol for DeviceNet Safety	false
Supporting protocol for EtherNet/IP	false
Supporting protocol for Foundation Fieldbus	false
Supporting protocol for INTERBUS	false
Supporting protocol for INTERBUS-Safety	false
Supporting protocol for KNX	false
Supporting protocol for LON	false
Supporting protocol for Modbus	false
Supporting protocol for other bus systems	false
Supporting protocol for PROFIBUS	false
Supporting protocol for PROFINET CBA	false
Supporting protocol for PROFINET IO	false
Supporting protocol for PROFIsafe	false
Supporting protocol for SafetyBUS p	false
Supporting protocol for SERCOS	false
Supporting protocol for SUCONET	false
Supporting protocol for TCP/IP	true
System memory	256 MB RAM, 512 MB nonvolatile memory, (approx. 73 MB free user memory)
Touch screen	Analog resistive, 4-wire, Actuation: 1 mon presses, Operating force: 10...110 g
Touch technology	Resistive touch
Type of display	TFT
USB ports	One USB host ports for connecting a USB mouse, keyboard, printer, and USB flash drives that are hot swappable, One USB device port for connecting a host personal computer
Useful project memory/user memory	73000 mb
Vibration	10...57 Hz, 0.012 peak-to-peak displacement, 57...500 Hz, 2 G peak acceleration
Voltage type of supply voltage	AC
Wall mounting/direct mounting	true
Weight, approx	Keypad: 728 g (1.60 lb), Touch: 594 g (1.31 lb)
Width of the front	152 mm
With alpha numeric keyboard	true
With colour display	false
With message indication	true
With message system (incl. buffer and confirmation)	true
With numeric keyboard	false
With printer output	true
With recipes	true
With SW interfaces	true
