Allen-Bradley – 1494C-DR644-A10 400 A Flange Mtd Cable Switch

MPN: 1494C-DR644-A10 · Brand: Rockwell Automation / Allen-Bradley

Price on request

Discontinued by Rockwell Automation / Allen-Bradley — we can still source the original 1494C-DR644-A10 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Programmable Controllers
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the 1494C-DR644-A10 now that it is discontinued?

Yes. Rockwell Automation / Allen-Bradley has discontinued the 1494C-DR644-A10, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 1494C-DR644-A10 be shipped?

1494C-DR644-A10 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1494C-DR644-A10 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1494C-DR644-A10 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1494C-DR644-A10, subject to availability and destination.

Allen-Bradley 1494C-DR644-A10 — 400 A Flange Mtd Cable Switch. Discontinued by Rockwell Automation on May 31, 2019. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued
Discontinued date	May 31, 2019
Replacement category (Rockwell)	Engineering Replacement
Repair options available	No

Specifications

Altitude	2000 m per IEC 947-1
Ambient enclosed temperature	-20 °C
Ambient open temperature	-20 °C
Ambient storage temperature	-40 °C
Cable mechanism	Cable operated mechanism 10 ft
Colour control element	Black
Conductor size	2 of #1 AWG...250 MCM (2 per lug), 2 of 185 mm²...250 MCM or 1 of #4 AWG...500 MCM
Continuous current (Ithe) rating	400A @ 600V AC per UL/CSA/NEMA
Device construction	Built-in device fixed built-in technique
Dielectric strength	2200V @ 1min
Disconnect mechanism	Right-hand mechanism
Electrical life cycle	6000 ops at rated current
Factory option	No fuse cover
Fuse/fuse clip type	Type R fuse clips
Hp rating	50Hp @ 250V DC per UL/CSA/NEMA
Insulation voltage	Rated 660V per IEC
KW rating (AC23), max	90 kW @ 220V AC @ 50Hz per IEC
Low level auxiliary 1 NO or 1 NC contact rating	C300, R150 per NEMA/EEMAC
Material	Switches, mechanisms and accessory kits: zinc-plated steel, RoHS compliant finish
Max. rated operation voltage Ue AC	600 V
Mechanical life operations	6000 (typical)
Motor drive integrated	false
Motor drive optional	false
Number of switches	1
Rated permanent current Iu	400 A
Recommended torque	Lug to terminal: 175 in-lb
Relative humidity	90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1
Short circuit withstand capability	200000A @ 600V AC: with Class J or Class R fuses
Standard auxiliary 1 NO or 1 NC contact rating	AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 17V @ 5mA minimum per IEC
Standard electrical interlock 1 NO and 1 NC contact rating	20A @ 480V AC, 0.25A @ 250V DC per NEMA/EEMAC
Standard electrical interlock 2 NO and 2 NC contact rating	20A @ 480V AC, 0.25A @ 250V DC per NEMA/EEMAC
Suitable for distribution board installation	true
Suitable for floor mounting	false
Suitable for front mounting 4-hole	false
Suitable for front mounting centre	false
Suitable for intermediate mounting	true
Switch and fuse rating (fusing)	600V 400 A switch, 400 A clips
Switch body material	Glass-filled thermoset plastic
Switching frequency, max	240 ops/m
Terminals	3/8 in-24 screw-lug, copper
Type of control element	Long turning handle
Type of electrical connection of main circuit	Screw connection
Version as emergency stop installation	false
Version as main switch	true
Version as maintenance-/service switch	true
Version as reversing switch	false
Version as safety switch	false
Voltage release optional	false
