Home / ABB / Single phase open / ABB VEL11308
ABB

ABB VEL11308

.75HP,1160RPM,1PH,60HZ,56C,3530LC,O

MPN
VEL11308
Price and lead time confirmed within 1 business day
Request a Quote

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • Ships via

What is the ABB VEL11308?

General Purpose Motor 0.750.000 Hp 115 V (VEL11308)

Specifications

Ordering

Catalog NumberVEL11308
Brand / LabelBaldor-Reliance
Country or Territory of OriginUnited States
Customs Tariff Number85013100
Minimum Order Quantity1 piece
Order Multiple1 piece

Electrical

Ambient Temperature40 °C
Duty Time60 Min
Efficiency Level2015 Small Motor Standard, Not Regulated / Exempt
Insulation ClassF
NEMA Design CodeL
Number of Phases1-phase
Number of Poles6P
Number of SpeedsSingle Speed
Power Factor95 %
Rated Efficiency81.50 %
Service Factor1.00
Type of DutyContinuous
Starting of MotorDirect On Line
Synchronous Speed (vsyn)1200 r/min
Output Power0.750.000 Hp

Mechanical

Drive End Flange TypeC-Face
Enclosure TypeODTF
Frame MaterialSteel
Motor Frame Size56C
Motor Base TypeNo Mounting
Mounting PositionF1
Brake PresentNo

Dimensions

Product Net Height13.123 in
Product Net Weight47 lb
Product Net Width13.75 in
Dimension Diagram35LYE019

Certificates and Declarations

Certification AgencyCURUSEEV
IDEA Granular Category Code (IGCC)1329 >> Single phase motor AC
ETIM 7EC001851 - Electric motor
