ABB SK829071-B – VH 300 Mechanical Interlock Unit
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ABB Block Contactors |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 0.13 kg |
| Country of origin | India |
| UPC / EAN | 7320500052693 |
Shipping & availability
When can SK829071-B be shipped?
SK829071-B is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up SK829071-B in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for SK829071-B and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SK829071-B, subject to availability and destination.
Mechanical interlock for two horizontally mounted contactors designed to prevent one of the contactors from closing while the other contactor is closed
Specifications
General
| Order code (ABB product ID) | SK829071-B |
| Type | VH 300 |
| Lifecycle | Active (current ABB product) |
| Country of origin | India |
Ordering
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85369001 |
Dimensions
| Product Net Width | 445 mm |
| Product Net Depth / Length | 30 mm |
| Product Net Height | 230 mm |
| Product Net Weight | 0.13 kg |
Technical
| Rated Frequency (f) | Supply Circuit 50 / 60 Hz |
| Conventional Free-air Thermal Current (I<sub>th</sub>) | acc. to IEC 60947-5-1, Θ = 40 °C 10 A |
| Rated Operational Current AC-15 (I<sub>e</sub>) | (500 V) 1 A, (690 V) 1 A, (24 / 127 V) 6 A, (220 / 240 V) 6 A, (380 / 400 V) 4 A |
| Rated Operational Current DC-13 (I<sub>e</sub>) | (24 V) 6 A, (48 V) 6 A, (72 V) 4 A, (125 V) 1.8 A, (250 V) 0.6 A |
| Short-Circuit Protective Devices | Auxiliary Circuit - gG Type Fuses 10 A |
| Rated Short-time Withstand Current Low Voltage (I<sub>cw</sub>) | for 0.1 s 140 A, for 1 s 100 A |
| Rated Insulation Voltage (U<sub>i</sub>) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V |
| Power Loss | at Rated Operating Conditions per Pole 0.1 W |
| Suitable For | EH260, EH300, EK175, EK210 |
| Product Name | Mechanical Interlock Unit |
Material Compliance
| RoHS Information | Following EU Directive 2011/65/EU |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | Product Not in WEEE Scope |
External Classifications and Standards
| Object Classification Code | R |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| UNSPSC | 39122221 |
| IDEA Granular Category Code (IGCC) | 5219 >> Switch part or accessory |
| E-Number (Norway) | 3214363 |
| E-Number (Sweden) | 3214363 |
