ABB SK825489-GF – EHDB280-21-22-RC 110V 50Hz 120V 60Hz Contactor

MPN: SK825489-GF · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ABB contactor spare parts (coils, arc chutes)
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	3.6 kg
UPC / EAN	7320500559062

Shipping & availability

When can SK825489-GF be shipped?

SK825489-GF is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SK825489-GF in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SK825489-GF and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SK825489-GF, subject to availability and destination.

EHDB280-21-22-RC 110V 50Hz 120V 60Hz Contactor

Specifications

General

Order code (ABB product ID)	SK825489-GF
Type	EHDB280-21-22-RC 110V 50Hz 120V 60Hz
Lifecycle	Active (current ABB product)

Ordering

Minimum Order Quantity	1 piece
Customs Tariff Number	85364900

Dimensions

Product Net Width	136 mm
Product Net Depth / Length	169 mm
Product Net Height	198 mm
Product Net Weight	3.6 kg

Technical

Number of Main Contacts NO	2
Number of Main Contacts NC	1
Number of Auxiliary Contacts NO	1
Number of Auxiliary Contacts NC	1
Number of Poles	3P
Rated Operational Current AC-1 (I<sub>e</sub>)	(690 V) 40 °C 280 A
Rated Control Circuit Voltage (U<sub>c</sub>)	50 Hz 110 V
Terminal Type	Main Circuit: Bars
Product Name	Block Contactor

Material Compliance

WEEE B2C / B2B	Business To Business
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards

Object Classification Code	Q
ETIM 7	EC000066 - Power contactor, AC switching
ETIM 8	EC000066 - Power contactor, AC switching
ETIM 9	EC000066 - Power contactor, AC switching
eClass	V11.0 : 27371003
UNSPSC	39121529
IDEA Granular Category Code (IGCC)	4755 >> Contactors
