ABB MVM3546C

.75KW,1725RPM,3PH,60HZ,D80C,3428M,T

MPN: MVM3546C
Category: Unit Handling

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the ABB MVM3546C?

LV Baldor IEC Motors 460 V (MVM3546C)

Specifications

Ordering

ABB Type Designation	.75KW,1725RPM,3PH,60HZ,D80C,3428M,T
Invoice Description	.75KW,1725RPM,3PH,60HZ,D80C,3428M,TEFC-
Product Name	LV Baldor IEC Motors
Product Type	Undefined
Country or Territory of Origin	United States
Customs Tariff Number	85015100
Stocked At (Warehouses)	Fort Smith, Arkansas, United States

Electrical

Temperature Class Default	--
Frequency (f)	60 Hz Hz
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	TEFC
IE Class Data (50 Hz)	IE Class NA
IE Class Data (60 Hz)	IE Class NA
IP Class	IP54
Insulation Class	ICLB
Direction of Rotation	Both sides
Two Speed Motor	No
Type of Duty	S1
Voltage Code	L

Mechanical

Frame Material	Steel
Frame Size	80
Bearing	6205
Bearing NDE	6203
Lubrication	Regreasable
IM Class	F2

Dimensions

Product Net Weight	14.528 kg kg
Gross Weight	14.528 kg kg

External Classifications and Standards

Standards

IEC_60034-1
