Home / ABB / MOTOR,3,3600,SD100,230/460,182T,NP
Available on request

MOTOR,3,3600,SD100,230/460,182T,NP

MPN: 1LE23211CA114AA3 · Brand: ABB
Price on request
Request a Quote

A real person replies, typically within 1 business day — see our privacy policy.

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

Quick facts

AvailabilityConfirmed on request
CategorySD100
Lifecycleactive
Warranty12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 1LE23211CA114AA3 be shipped?

1LE23211CA114AA3 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1LE23211CA114AA3 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1LE23211CA114AA3 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1LE23211CA114AA3, subject to availability and destination.

Severe Duty Motor 3 Hp 200 V (1LE23211CA114AA3)

Specifications

Ordering

Catalog Number1LE23211CA114AA3
Brand / LabelABB NEMA Motors
Country or Territory of OriginMexico
Customs Tariff Number8501520400
Minimum Order Quantity1 piece
Order Multiple1 piece

Electrical

Ambient Temperature40 °C
Efficiency LevelPremium Efficiency (NEMA 12-12)
Insulation ClassF
NEMA Design CodeB
Number of Phases3-phase
Number of Poles2P
Number of Speedssingle_speed
Power Factor85.5 %
Rated Efficiency86.5 %
Service Factor1.15
Temperature ClassT3
Type of DutyContinuous
Starting of MotorDirect on line
Synchronous Speed (vsyn)3000 r/min, 3600 r/min
Output Power3 Hp, 2 Hp

Mechanical

Drive End Flange TypeStandard
Enclosure TypeTEFC
Explosion Proof Group ClassClass I, Group A, B, C & D A
Frame MaterialCast_Iron
Motor Frame Size182T
Motor Base TypeFoot Mounted
Mounting PositionF1
Brake PresentNo

Dimensions

Product Net Height0 in
Product Net Weight51 lb
Product Net Width0 in
