ABB 3GLP314930-BDG

M3LP 315KHC 8

MPN: 3GLP314930-BDG
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GLP314930-BDG?

IE2 Liquid Cooled Motors, 200 kW, 400 V (3GLP314930-BDG)

Specifications

Ordering

ABB Type Designation	M3LP 315KHC 8
Invoice Description	M3LP 315KHC 8
Product Name	3-Phase squirrel cage motor
Product Type	3LP2__water_cooled_motor_IE2
Country or Territory of Origin	Finland
Customs Tariff Number	85015381
Replaced Product ID (OLD)	3GLP314830-BDG
Medium Description	200kW, 8 Poles, Frame Size 315, 3 Phases, 400V, 50Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GLP314930-BDG)
Short Description	200kW, 8 P, Frame Size 315, 3PH, 400V, 50Hz, IP55, IMB5/IM3001

Electrical

Connection Configuration	D
Temperature Class Default	--
Input Voltage (Uin)	400 V V
Frequency (f)	50 Hz Hz
Output Power	200 kW kW
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC71W
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 93.5 %, Partial Load (75%) 93.9 %, Partial Load (50%) 93.5 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	8
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D

Mechanical

Frame Material	Aluminum
Frame Size	315
Bearing	6319/C3
Bearing NDE	6316/C3
IM Class	IMB5 IM3001
Terminator Box Location	Top

Dimensions

Product Net Depth / Length	1336 mm mm
Product Net Height	643 mm mm
Product Net Width	666 mm mm
Product Net Weight	1600 kg kg
Gross Weight	1620 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
