ABB 3GET282732-AUB

MPN: 3GET282732-AUB
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GET282732-AUB?

HDP Induction Motors, 370 kW, 690 V (3GET282732-AUB)

Specifications

Ordering

ABB Type Designation	M3ET 280C 4
Invoice Description	M3ET 280C 4
Product Name	High dynamic performance motors
Product Type	3ETB__M3ET__HDP__IP55_
Country or Territory of Origin	Finland, China
Customs Tariff Number	85015381
Medium Description	370kW, 4P, Frame Size 280, 3 Phases, 690V, 50Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GET282732-AUB)
Short Description	370kW, 4P, Frame Size 280, 3PH, 690V, 50Hz, IP55, IMB3/IM1001

Electrical

Connection Configuration	D
Temperature Class Default	--
Input Voltage (Uin)	690 V V
Frequency (f)	50 Hz Hz
Motor Operational Voltage	640 V V
Operating Frequency (fsw)	50.400 Hz Hz
Output Power	370 kW kW
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC416
IE Class Data (50 Hz)	IE Class NA, Full Load (100%) 95.9 %, Partial Load (75%) 96.4 %, Partial Load (50%) 96.5 %
IP Class	IP55
Insulation Class	ICLH
Direction of Rotation	Both sides
Number of Poles (High)	4
Two Speed Motor	No
Type of Duty	S9
Voltage Code	U

Mechanical

Frame Material	Welded Steel
Frame Size	280
Bearing	6322/C3
Bearing NDE	6316/C4VL0241
IM Class	IMB3 IM1001
Terminator Box Location	D-End top

Dimensions

Product Net Depth / Length	1770 mm mm
Product Net Height	1445 mm mm
Product Net Width	787 mm mm
Product Net Weight	2200 kg kg
Gross Weight	2220 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
