ABB M2VAB-B3-6C00-4P

Motor M2VAB de aluminio, 6,0CV (4,5kW), 4 polos, forma construtiva B3T

MPN: M2VAB-B3-6C00-4P
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB M2VAB-B3-6C00-4P?

Rendimento IR3: 89.5% (100%) // 89.3% (75%) // 88.6% (50%) NBR17094-1

Specifications

Ordering

ABB Type Designation	M2VAB-B3-6C00-4P
Invoice Description	Motor M2VAB de aluminio, 6,0CV (4,5kW), 4 polos, forma construtiva B3T
Product Name	Low Voltage Motor
Product Type	BVA3__M2VAB_IR3_AA
Country or Territory of Origin	Brazil
Customs Tariff Number	85015210
Stocked At (Warehouses)	Bairro Santo Antonio, Brazil
Medium Description	4,5kW, 4P, Carcaca 112, Trifasico, 220/380/440V, 60Hz, IP55, Montagem IMB3 IM1001 (M2VAB-B3-6C00-4P)

Electrical

Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (60 Hz)	IE Class IE3, Full Load (100%) 89.5 %, Partial Load (75%) 89.3 %, Partial Load (50%) 88.6 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	4
Two Speed Motor	No
Type of Duty	S1
Voltage Code	S

Mechanical

Frame Material	Cast Iron
Frame Size	112
Bearing	6207 ZZ
Bearing NDE	6206 ZZ
IM Class	IMB3 IM1001
Terminator Box Location	D-End top

Dimensions

Product Net Depth / Length	408 mm mm
Product Net Height	312 mm mm
Product Net Width	226 mm mm
Product Net Weight	43.2 kg kg
Gross Weight	0 kg kg
