ABB 3GQP351450-ADL

M2QAP 355MLE 2

MPN: 3GQP351450-ADL
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GQP351450-ADL?

(3GQP351450-ADL)

Specifications

Ordering

ABB Type Designation	M2QAP 355MLE 2
Invoice Description	M2QAP 355MLE 2
Product Name	3-Phase squirrel cage motor
Product Type	CQP3__M2QP_IE3_CI
Country or Territory of Origin	China
Customs Tariff Number	85015394
Medium Description	?kW, 2P, Frame Size 355, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GQP351450-ADL) kW
Short Description	?kW, 2P, Frame Size 355, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 95.8 %, Partial Load (75%) 95.8 %, Partial Load (50%) 95.2 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D

Mechanical

Frame Material	Cast Iron
Frame Size	355
Bearing	6319/C3
Bearing NDE	6319/C3
IM Class	IMB3 IM1001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	1811.903 kg kg
Gross Weight	1841.903 kg kg

External Classifications and Standards

UNSPSC

26101100
