ABB 3GQA351420-ADL

M2QA 355MLB2

MPN: 3GQA351420-ADL
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the ABB 3GQA351420-ADL?

(3GQA351420-ADL)

Specifications

Ordering

ABB Type Designation	M2QA 355MLB2
Invoice Description	M2QA 355MLB2
Product Name	3 PHASE AC MOTOR
Product Type	CQA3__M2QA_IE3_CI
Country or Territory of Origin	China
Customs Tariff Number	85015220
Stocked At (Warehouses)	Shanghai, China
Medium Description	?kW, 2P, Frame Size 355, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GQA351420-ADL) kW
Short Description	?kW, 2P, Frame Size 355, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 95.8 %, Partial Load (75%) 96.0 %, Partial Load (50%) 95.6 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D

Mechanical

Frame Material	Cast Iron
Frame Size	355
Bearing	6319M/C4
Bearing NDE	6319M/C4
Lubrication	For life
IM Class	IMB3 IM1001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	1658.5 kg kg
Gross Weight	1663.5 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

Standards	IEC 60034-1
UNSPSC	26101100, 39120000

3GQA351420-ADL: frequently asked questions

When can 3GQA351420-ADL be shipped?

3GQA351420-ADL is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GQA351420-ADL in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GQA351420-ADL and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GQA351420-ADL, subject to availability and destination.
