ABB 3GQA181410-BDP

M2QA 180MLA 2

MPN: 3GQA181410-BDP
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GQA181410-BDP?

M2QA 180MLA 2

Specifications

Ordering

ABB Type Designation	M2QA 180MLA 2
Invoice Description	M2QA 180MLA 2
Product Name	3-Phase squirrel cage motor
Product Type	CQA5__M2QA_IE4_CI
Country or Territory of Origin	China
Customs Tariff Number	85015230

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE5, Full Load (100%) 95.1 %, Partial Load (75%) 95.2 %, Partial Load (50%) 94.5 %
IE Class Data (60 Hz)	IE Class IE4, Full Load (100%) 94.7 %, Partial Load (75%) 94.4 %, Partial Load (50%) 93.2 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D

Mechanical

Frame Material	Cast Iron
Frame Size	180
Bearing	6310-2Z/C3
Bearing NDE	6210-2Z/C3
IM Class	IMB5 IM3001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	263 kg kg
Gross Weight	273 kg kg

External Classifications and Standards

UNSPSC

26101100

3GQA181410-BDP: frequently asked questions

When can 3GQA181410-BDP be shipped?

3GQA181410-BDP is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GQA181410-BDP in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GQA181410-BDP and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GQA181410-BDP, subject to availability and destination.
