ABB 3GQA161310-ADL
- MPN
- 3GQA161310-ADL
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the ABB 3GQA161310-ADL?
(3GQA161310-ADL)
Specifications
Ordering
| ABB Type Designation | M2QA 160MA2 |
| Invoice Description | M2QA 160MA2 |
| Product Name | 3 PHASE AC MOTOR |
| Product Type | CQA3__M2QA_IE3_CI |
| Country or Territory of Origin | China |
| Customs Tariff Number | 85015220 |
| Stocked At (Warehouses) | Shanghai, China |
| Medium Description | ?kW, 2P, Frame Size 160, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GQA161310-ADL) kW |
| Short Description | ?kW, 2P, Frame Size 160, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW |
Electrical
| Temperature Class Default | -- |
| Altitude | 1000 m m |
| Ambient Temperature | 40 °C |
| IC Class | IC411 |
| IE Class Data (50 Hz) | IE Class IE3, Full Load (100%) 91.2 %, Partial Load (75%) 91.4 %, Partial Load (50%) 90.8 % |
| IP Class | IP55 |
| Insulation Class | ICLF |
| Direction of Rotation | Both sides |
| Number of Poles (High) | 2 |
| Two Speed Motor | No |
| Type of Duty | S1 |
| Voltage Code | D |
Mechanical
| Frame Material | Cast Iron |
| Frame Size | 160 |
| Bearing | 6309-2Z/C3 |
| Bearing NDE | 6209-2Z/C3 |
| Lubrication | For life |
| IM Class | IMB3 IM1001 |
| Terminator Box Location | D-End top |
Dimensions
| Product Net Weight | 127.9 kg kg |
| Gross Weight | 130.9 kg kg |
Environmental
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) cm |
External Classifications and Standards
| Standards | IEC 60034-1 |
| UNSPSC | 26101100, 39120000 |
