Home / ABB / Flameproof IEC Low voltage motors / ABB 3GJA081330-ASCIN

ABB 3GJA081330-ASCIN

M2JAP 80MC 2

MPN: 3GJA081330-ASCIN
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GJA081330-ASCIN?

M2JAP 80MC 2

Specifications

Ordering

ABB Type Designation	M2JAP 80MC 2
Invoice Description	M2JAP 80MC 2
Product Name	3-Phase squirrel cage motor
Product Type	IJA2__M2JAP_IE2_Flameproof_Exd_motor
Country or Territory of Origin	India
Customs Tariff Number	85015220
Medium Description	1.1kW, 2P, Frame Size 80, 3 Phases, 415V, 50Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GJA081330-ASCIN)
Short Description	1.1kW, 2P, Frame Size 80, 3PH, 415V, 50Hz, IP55, IMB3/IM1001

Electrical

Temperature Class Default	T4
Altitude	1000 m m
Ambient Temperature	50 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 81.8 %, Partial Load (75%) 81.6 %, Partial Load (50%) 79.1 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	S
EX-Protection	Exdb
Gas Group	IIB

Mechanical

Frame Material	Cast Iron
Frame Size	80
Bearing	6205-2Z/C3
Bearing NDE	6204-2Z/C3
IM Class	IMB3 IM1001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	47 kg kg
Gross Weight	50 kg kg

External Classifications and Standards

UNSPSC

26101100
