ABB M2BAF 180MLA 4

(3GBA182410-BDKCN)

MPN: M2BAF 180MLA 4
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB M2BAF 180MLA 4?

(3GBA182410-BDKCN)

Specifications

Ordering

ABB Type Designation	M2BAF 180MLA 4
Invoice Description	M2BAF 180MLA 4
Product Name	3-Phase squirrel cage motor
Product Type	CBF3__M2BAF_IE3_CI
Country or Territory of Origin	China
Customs Tariff Number	85015230
Stocked At (Warehouses)	Shanghai, China, Guangzhou, China, China
Medium Description	?kW, 4P, Frame Size 180, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GBA182410-BDKCN) kW
Short Description	?kW, 4P, Frame Size 180, 3PH, 400V, ?Hz, IP55, IMB5/IM3001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 92.6 %, Partial Load (75%) 92.9 %, Partial Load (50%) 92.8 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	4
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D

Mechanical

Frame Material	Cast Iron
Frame Size	180
Bearing	6310-2Z/C3
Bearing NDE	6309-2Z/C3
IM Class	IMB5 IM3001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	172 kg kg
Gross Weight	182 kg kg

External Classifications and Standards

UNSPSC

26101100
