Home / ABB / Pressure Washer motor / ABB EPL1322M

ABB

ABB EPL1322M

2HP,1725RPM,1PH,60HZ,56,3546LC,OPEN

MPN: EPL1322M
Category: Pressure Washer motor

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the ABB EPL1322M?

Definite Purpose 2 Hp 115 V (EPL1322M)

Specifications

Ordering

Catalog Number	EPL1322M
Brand / Label	Baldor-Reliance
Country or Territory of Origin	United States
Customs Tariff Number	85015220
Minimum Order Quantity	1 piece
Order Multiple	1 piece

Electrical

Ambient Temperature	40 °C
Efficiency Level	2015 Small Motor Standard, Not Regulated / Exempt
Insulation Class	F
NEMA Design Code	L
Number of Phases	1-phase
Number of Poles	4P
Number of Speeds	Single Speed
Power Factor	93 %
Rated Efficiency	84.50 %
Service Factor	1.15
Type of Duty	Continuous
Starting of Motor	Direct On Line
Synchronous Speed (vsyn)	1800 r/min
Output Power	2 Hp

Mechanical

Drive End Flange Type	Standard
Enclosure Type	OPEN
Frame Material	Steel
Motor Frame Size	56
Motor Base Type	Rigid
Mounting Position	F1
Brake Present	No

Dimensions

Product Net Height	13.123 in
Product Net Weight	66 lb
Product Net Width	13.75 in

Certificates and Declarations

Certification Agency

C UR US ENERGY
