ABB

ABB 3GVA063350-BSR

M2VAM 63ME 6

MPN: 3GVA063350-BSR
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GVA063350-BSR?

(3GVA063350-BSR)

Specifications

Ordering

ABB Type Designation	M2VAM 63ME 6
Invoice Description	M2VAM 63ME 6
Product Name	3-Phase squirrel cage motor
Product Type	MVA2__M2VAM_IE2_AA
Country or Territory of Origin	Poland
Customs Tariff Number	85015100
Medium Description	?kW, 6P, Frame Size 63, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GVA063350-BSR) kW
Short Description	?kW, 6P, Frame Size 63, 3PH, 400V, ?Hz, IP55, IMB5/IM3001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	50 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 50.6 %, Partial Load (75%) 50.7 %, Partial Load (50%) 47.0 %
IE Class Data (60 Hz)	IE Class IE2, Full Load (100%) 50.5 %, Partial Load (75%) 50.6 %, Partial Load (50%) 47.3 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	6
Two Speed Motor	No
Type of Duty	S1
Voltage Code	S

Mechanical

Frame Material	Aluminum
Frame Size	63
Bearing	6201-2Z/C3
Bearing NDE	6201-2Z/C3
IM Class	IMB5 IM3001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	5.6 kg kg
Gross Weight	6.6 kg kg

Environmental

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
