ABB 3GRP283326-BDG

MPN: 3GRP283326-BDG
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GRP283326-BDG?

M3RP 280MB 6

Specifications

Ordering

ABB Type Designation	M3RP 280MB 6
Invoice Description	M3RP 280MB 6
Product Name	3-Phase squirrel cage motor
Product Type	3RP0__M3RP_CI
Country or Territory of Origin	Finland
Customs Tariff Number	85015230
Replaced Product ID (OLD)	3GRP283320-BXG
Medium Description	22kW, 6 Poles, Frame Size 280, 3 Phases, 400V, 50Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GRP283326-BDG)
Short Description	22kW, 6P, Frame Size 280, 3PH, 400V, 50Hz, IP55, IMB5/IM3001

Electrical

Connection Configuration	Y
Temperature Class Default	--
Input Voltage (Uin)	400 V V
Frequency (f)	50 Hz Hz
Motor Operational Voltage	400 V V
Operating Frequency (fsw)	50.000 Hz Hz
Output Power	22 kW kW
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC410
IE Class Data (50 Hz)	IE Class NA, Full Load (100%) 93.1 %, Partial Load (75%) 92.8 %, Partial Load (50%) 91.3 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	6
Two Speed Motor	No
Type of Duty	S9
Voltage Code	D

Mechanical

Frame Material	Cast Iron
Frame Size	280
Bearing	6316/C3
Bearing NDE	6316/C3
IM Class	IMB5 IM3001
Terminator Box Location	N-End top

Dimensions

Product Net Weight	620 kg kg
Gross Weight	640 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
