ABB 3GLL202467-BDM

M3LL 200MLF 4

MPN: 3GLL202467-BDM
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GLL202467-BDM?

IE4 Liquid Cooled SynRM Motors, 160 kW, 400 V (3GLL202467-BDM)

Specifications

Ordering

ABB Type Designation	M3LL 200MLF 4
Invoice Description	M3LL 200MLF 4
Product Name	3Phase Synchronous reluctance motor
Product Type	3LL4__M3LL_IE4__Water_cooled_SynRM
Country or Territory of Origin	Finland
Customs Tariff Number	85015381
Medium Description	160kW, 4 Poles, Frame Size 200, 3 Phases, 400V, 50Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GLL202467-BDM)
Short Description	160kW, 4 P, Frame Size 200, 3PH, 400V, 50Hz, IP55, IMB5/IM3001

Electrical

Connection Configuration	D
Temperature Class Default	--
Input Voltage (Uin)	400 V V
Frequency (f)	50 Hz Hz
Motor Operational Voltage	430 V V
Operating Frequency (fsw)	120.000 Hz Hz
Output Power	160 kW kW
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC71W
IE Class Data (50 Hz)	IE Class IE4, Full Load (100%) 95.4 %, Partial Load (75%) 95.2 %, Partial Load (50%) 94.5 %
IE Class Data (60 Hz)	IE Class IE4, Full Load (100%) 95.4 %, Partial Load (75%) 95.2 %, Partial Load (50%) 94.2 %
IP Class	IP55
Insulation Class	ICLH
Direction of Rotation	Both sides
Number of Poles (High)	4
Two Speed Motor	No
Type of Duty	S9
Voltage Code	D

Mechanical

Frame Material	Aluminum
Frame Size	200
Bearing	6312/C3
Bearing NDE	6310/C3VL0241
IM Class	IMB5 IM3001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	388 kg kg
Gross Weight	398 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
