What is the ABB 3GKP133240-CSL?

(3GKP133240-CSL)

Specifications

Ordering

ABB Type Designation	M3KP 132SMD 6
Invoice Description	M3KP 132SMD 6
Product Name	3-Phase squirrel cage motor
Product Type	5KP3__M3KP_IE3_Flameproof_Exde_motor
Country or Territory of Origin	Finland
Customs Tariff Number	85015220

Electrical

Temperature Class Default	T4
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 88.0 %, Partial Load (75%) 87.8 %, Partial Load (50%) 85.5 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	6
Two Speed Motor	No
Voltage Code	S
EX-Protection	Exde
Gas Group	IIB

Mechanical

Frame Material	Cast Iron
Frame Size	132
Bearing	6208-2Z/C3
Bearing NDE	6208-2Z/C3
IM Class	IMB14 IM3601
Terminator Box Location	Top

Dimensions

Product Net Weight	105 kg kg
Gross Weight	110 kg kg

Environmental

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
