What is the ABB 3GKP083320-CDJ?

(3GKP083320-CDJ)

Specifications

Ordering

ABB Type Designation	M3KP 80MB 6
Invoice Description	M3KP 80MB 6
Product Name	3-Phase squirrel cage motor
Product Type	3KP0__M3KP_IE2_Flameproof_Exde_motor
Country or Territory of Origin	Finland
Customs Tariff Number	85015100
Replaced Product ID (OLD)	3GKP083320-CDH
Medium Description	?kW, 6P, Frame Size 80, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB14/IM3601 Mounting (3GKP083320-CDJ) kW
Short Description	?kW, 6P, Frame Size 80, 3PH, 400V, ?Hz, IP55, IMB14/IM3601 kW

Electrical

Temperature Class Default	T4
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 73.1 %, Partial Load (75%) 73.6 %, Partial Load (50%) 70.7 %
IE Class Data (60 Hz)	IE Class IE2, Full Load (100%) 68.0 %, Partial Load (75%) 66.8 %, Partial Load (50%) 61.3 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	6
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D
EX-Protection	Exdbeb
Gas Group	IIB

Mechanical

Frame Material	Cast Iron
Frame Size	80
Bearing	6205-2Z/C3
Bearing NDE	6204-2Z/C3
IM Class	IMB14 IM3601
Terminator Box Location	D-End top

Dimensions

Product Net Weight	39 kg kg
Gross Weight	42 kg kg

Environmental

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
