ABB 3GJP401830-AEG
M3JP 400LKC 2
- MPN
- 3GJP401830-AEG
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the ABB 3GJP401830-AEG?
(3GJP401830-AEG)
Specifications
Ordering
| ABB Type Designation | M3JP 400LKC 2 |
| Invoice Description | M3JP 400LKC 2 |
| Product Name | 3-Phase squirrel cage motor |
| Product Type | 3JP2__M3JP_IE2_Flameproof_Ex_db_motor |
| Country or Territory of Origin | Finland |
| Customs Tariff Number | 85015394 |
Electrical
| Temperature Class Default | T4 |
| Altitude | 1000 m m |
| Ambient Temperature | 40 °C |
| IC Class | IC411 |
| IE Class Data (50 Hz) | IE Class IE4, Full Load (100%) 97.5 %, Partial Load (75%) 97.4 %, Partial Load (50%) 96.9 % |
| IP Class | IP55 |
| Insulation Class | ICLF |
| Number of Poles (High) | 2 |
| Two Speed Motor | No |
| Type of Duty | S1 |
| Voltage Code | E |
| EX-Protection | Exdb |
| Gas Group | IIB |
Mechanical
| Frame Material | Cast Iron |
| Frame Size | 400 |
| Bearing | 6317M/C3 |
| Bearing NDE | 6317M/C3 |
| IM Class | IMB3 IM1001 |
| Terminator Box Location | Top |
Dimensions
| Product Net Weight | 3580 kg kg |
| Gross Weight | 3620 kg kg |
Environmental
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) cm |
| SCIP | 297e96db-dbee-43c1-ad2d-ddd583080bb8 Finland |
External Classifications and Standards
| UNSPSC | 26101100 |
3GJP401830-AEG: frequently asked questions
When can 3GJP401830-AEG be shipped?
3GJP401830-AEG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3GJP401830-AEG in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3GJP401830-AEG and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GJP401830-AEG, subject to availability and destination.
