What is the ABB 3GJP104510-CEJ?

(3GJP104510-CEJ)

Specifications

Ordering

ABB Type Designation	M3JP 100LA 8
Invoice Description	M3JP 100LA 8
Product Name	3-Phase squirrel cage motor
Product Type	3JP0__M3JP_IE2_Flameproof_Exd_motor
Country or Territory of Origin	Finland
Customs Tariff Number	85015100
Replaced Product ID (OLD)	3GJP104510-CEH
Medium Description	0.75kW, 8P, Frame Size 100, 3 Phases, 500V, 50Hz, IP55 Enclosure, IMB14/IM3601 Mounting (3GJP104510-CEJ)
Short Description	0.75kW, 8P, Frame Size 100, 3PH, 500V, 50Hz, IP55, IMB14/IM3601

Electrical

Temperature Class Default	T4
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 72.8 %, Partial Load (75%) 72.0 %, Partial Load (50%) 67.7 %
IE Class Data (60 Hz)	IE Class IE2, Full Load (100%) 74.2 %, Partial Load (75%) 72.5 %, Partial Load (50%) 67.4 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	8
Two Speed Motor	No
Type of Duty	S1
Voltage Code	E
EX-Protection	Exdb
Gas Group	IIB

Mechanical

Frame Material	Cast Iron
Frame Size	100
Bearing	6206-2Z/C3
Bearing NDE	6205-2Z/C3
IM Class	IMB14 IM3601
Terminator Box Location	D-End top

Dimensions

Product Net Weight	64 kg kg
Gross Weight	69 kg kg

Environmental

WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm) cm
SCIP	297e96db-dbee-43c1-ad2d-ddd583080bb8 Finland

External Classifications and Standards

UNSPSC

26101100
