ABB 3GJM201430-BSG

M3JM 200MLC 2

MPN: 3GJM201430-BSG
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GJM201430-BSG?

M3JM 200MLC 2

Specifications

Ordering

ABB Type Designation	M3JM 200MLC 2
Invoice Description	M3JM 200MLC 2
Product Name	3-Phase squirrel cage motor
Product Type	3JM2__M3JM_IE2_Group_I_Flameproof_Exd_mining_motor
Country or Territory of Origin	Finland
Customs Tariff Number	85015230
Medium Description	?kW, 2P, Frame Size 200, 3 Phases, 400V, ?Hz, IP66 Enclosure, IMB5/IM3001 Mounting (3GJM201430-BSG) kW
Short Description	?kW, 2P, Frame Size 200, 3PH, 400V, ?Hz, IP66, IMB5/IM3001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 93.6 %, Partial Load (75%) 93.9 %, Partial Load (50%) 93.4 %
IP Class	IP66
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	S
EX-Protection	Exdb

Mechanical

Frame Material	Cast Iron
Frame Size	200
Bearing	6312M/C3
Bearing NDE	6310M/C3
IM Class	IMB5 IM3001
Terminator Box Location	Top

Dimensions

Product Net Weight	351 kg kg
Gross Weight	361 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100, 39120000

3GJM201430-BSG: frequently asked questions

When can 3GJM201430-BSG be shipped?

3GJM201430-BSG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GJM201430-BSG in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GJM201430-BSG and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GJM201430-BSG, subject to availability and destination.
