ABB 3GGP253240-ADK

M3GP 250SMD 6

MPN: 3GGP253240-ADK

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GGP253240-ADK?

Dust Ignition Proof IE3 Motors, 37 kW, 400 V (3GGP253240-ADK)

Specifications

Ordering

ABB Type Designation	M3GP 250SMD 6
Invoice Description	M3GP 250SMD 6
Product Name	3-Phase squirrel cage motor
Product Type	3GP3__M3GP_IE3_CI
Country or Territory of Origin	Finland
Customs Tariff Number	85015230
Medium Description	37kW, 6 Poles, Frame Size 250, 3 Phases, 400V, 50Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GGP253240-ADK)
Short Description	37kW, 6P, Frame Size 250, 3PH, 400V, 50Hz, IP55, IMB3/IM1001

Electrical

Connection Configuration	D
Temperature Class Default	T3
Input Voltage (Uin)	400 V V
Frequency (f)	50 Hz Hz
Output Power	37 kW kW
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 94.3 %, Partial Load (75%) 94.7 %, Partial Load (50%) 94.4 %
IP Class	IP55
Insulation Class	ICLF
Number of Poles (High)	6
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D
EX-Protection	Exec
Gas Group	IIC

Mechanical

Frame Material	Cast Iron
Frame Size	250
Bearing	6315/C3
Bearing NDE	6213/C3
IM Class	IMB3 IM1001

Dimensions

Product Net Depth / Length	884 mm mm
Product Net Height	626 mm mm
Product Net Width	508 mm mm
Product Net Weight	522 kg kg
Gross Weight	532 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
