What is the ABB 3GBP083340-BCK?

(3GBP083340-BCK)

Specifications

Ordering

ABB Type Designation	M3BP 80MD 6
Invoice Description	M3BP 80MD 6
Product Name	3-Phase squirrel cage motor
Product Type	3BP3__M3BP_IE3_CI
Country or Territory of Origin	Finland, China
Customs Tariff Number	85015100

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 77.1 %, Partial Load (75%) 78.6 %, Partial Load (50%) 77.7 %
IE Class Data (60 Hz)	IE Class IE3, Full Load (100%) 75.5 %, Partial Load (75%) 75.6 %, Partial Load (50%) 73.2 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	6
Two Speed Motor	No
Type of Duty	S1
Voltage Code	C

Mechanical

Frame Material	Cast Iron
Frame Size	80
Bearing	6204-2Z/C3
Bearing NDE	6203-2Z/C3
IM Class	IMB5 IM3001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	16 kg kg
Gross Weight	24 kg kg

Environmental

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

Standards	IEC 60034-1
UNSPSC	26101100
