Home / ABB / NEMA AC Motors / ABB 3GBN951310-AEK

ABB

ABB 3GBN951310-AEK

MPN: 3GBN951310-AEK
Category: NEMA AC Motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GBN951310-AEK?

(3GBN951310-AEK)

Specifications

Ordering

ABB Type Designation	M3BN 5010MA 2
Invoice Description	M3BN 5010MA 2
Product Name	3-Phase squirrel cage motor
Product Type	3BN3__M3BN_IE3
Country or Territory of Origin	Finland
Customs Tariff Number	85015381

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (60 Hz)	IE Class IE5, Full Load (100%) 97.0 %, Partial Load (75%) 96.7 %, Partial Load (50%) 95.7 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	E

Mechanical

Frame Material	Cast Iron
Frame Size	5000
Bearing	6317M/C3
Bearing NDE	6317M/C3VL0241
IM Class	IMB3 IM1001
Terminator Box Location	D-End left side

Dimensions

Product Net Weight	2010 kg kg
Gross Weight	2050 kg kg

Environmental

WEEE Category	4. Large Equipment (Any External Dimension More Than 50 cm) cm
SCIP	a68594ba-db5c-4ba6-aabc-a40fc86bf202 Finland

External Classifications and Standards

UNSPSC

26101100

3GBN951310-AEK: frequently asked questions

When can 3GBN951310-AEK be shipped?

3GBN951310-AEK is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GBN951310-AEK in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GBN951310-AEK and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GBN951310-AEK, subject to availability and destination.
