Home / ABB / Flameproof IEC Low voltage motors / ABB 3GBA073310-ADCCN

ABB

ABB 3GBA073310-ADCCN

M2BAX 71MA 6

MPN: 3GBA073310-ADCCN
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GBA073310-ADCCN?

(3GBA073310-ADCCN)

Specifications

Ordering

ABB Type Designation	M2BAX 71MA 6
Invoice Description	M2BAX 71MA 6
Product Name	3-Phase squirrel cage motor
Product Type	CBA2__M2BAX_CI
Country or Territory of Origin	China
Customs Tariff Number	85015100
Stocked At (Warehouses)	Shanghai, China, Guangzhou, China

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 59.0 %, Partial Load (75%) 56.5 %, Partial Load (50%) 50.9 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	6
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D

Mechanical

Frame Size	71
Bearing	6203-2Z/C3
Bearing NDE	6202-2Z/C3
Lubrication	For life
IM Class	IMB3 IM1001

Dimensions

Product Net Weight	9 kg kg
Gross Weight	9 kg kg

Environmental

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

Standards	IEC 60034-1
UNSPSC	26101100
