What is the ABB 3GAA104520-BGE?

(3GAA104520-BGE)

Specifications

Ordering

ABB Type Designation	M3AA 100LB 8
Invoice Description	M3AA 100LB 8
Product Name	3-Phase squirrel cage motor
Product Type	3AA2__M3AA_IE2_AA
Country or Territory of Origin	Finland
Customs Tariff Number	85015220
Replaced Product ID (OLD)	3GAA104442-BGE

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 77.7 %, Partial Load (75%) 76.4 %, Partial Load (50%) 72.1 %
IP Class	IP55
Insulation Class	ICLF
Number of Poles (High)	8
Two Speed Motor	No
Type of Duty	S1
Voltage Code	G G

Mechanical

Frame Material	Aluminum
Frame Size	100
Bearing	6306-2Z/C3
Bearing NDE	6205-2Z/C3
IM Class	IMB5 IM3001

Dimensions

Product Net Weight	23 kg kg
Gross Weight	28 kg kg

Environmental

WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm) cm
SCIP	27ac6190-e1ce-4080-8654-6552aaabbe58 Finland

External Classifications and Standards

UNSPSC

26101100
