ABB EM7082T

25//20HP,1180//985RPM,3PH,60//50HZ

MPN
EM7082T
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare ABB parts? We buy surplus →

What is the ABB EM7082T?

20.000 hp, 25.000 hp, 1180//985 RPM, 3PH, 230/460//190/380 V, 60//50 Hz, XPFC, 324T, F1

Specifications

Additional Information

ABB Type Designation25//20HP,1180//985RPM,3PH,60//50HZ,
Ambient Temperature40 °C
Brake PresentNo
Brand / LabelBaldor-Reliance
Catalog NumberEM7082T
Certification AgencyCSA, UL
Country or Territory of OriginUnited States
Customs Tariff Number85015230
DesignA A
Dimension Diagram12LYL018
Efficiency LevelIE3, Not Regulated / Exempt, Premium Efficiency (NEMA 12-12)
Enclosure TypeXPFC
ETIM 7EC001851 - Electric motor
Explosion Proof Group ClassCLI GP D, CLII GP F,G G
Explosion ProtectionExplosion-proof
Frame MaterialIron
Frame SizeUndefined
Frequency (f)50 Hz, 60 Hz Hz
Global Commercial AliasEM7082T
Gross Weight334.598 kg kg
Horsepower Rating UL/CSA20.000 Hp, 25.000 Hp
IDEA Granular Category Code (IGCC)1328 >> Multi phase motor AC
Insulation ClassB
Invoice Description20.000 hp, 25.000 hp, 1180//985 RPM, 3PH, 230/460//190/380 V, 60//50 Hz, XPFC, 324T, F1 V
Made To OrderNo
Marketing Description20.000 hp, 25.000 hp, 1180//985 RPM, 3PH, 230/460//190/380 V, 60//50 Hz, XPFC, 324T, F1 V
Minimum Order Quantity0.000 piece
Motor Base TypeRigid
Motor Frame Size324T
NEMA Design CodeA A
Number of Phases3-phase
Number of Poles6P
Number of SpeedsSingle Speed
Order Multiple0.000 piece
Power Factor79 %
Product Name-
Product Net Depth / Length32.00 in
Product Net Weight334.598 kg kg
Quote OnlyNo
Rated Current (In)63 A, 32 A, 62 A, 31 A A
Rated Efficiency93.0 %
Rated Speed985 r/min, 1,180 r/min
Selling Unit of Measurepiece
Service Factor1.00
Service Factor Percentage1.00 %
Shaft Diameter2.125 in
StandardsNEMA
Starting of MotorDirect On Line
Stocked At (Warehouses)China, Fort Smith, Arkansas, United States, Alaska, United States
Temperature ClassT3C
Type of DutyCONT
UNSPSC26101115
Voltage Rating460 V, 380 V, 230 V, 190 V V
