Home / ABB / ABB A Contactors / AE110-30-11 125V DC Contactor

Available on request

ABB 1SFL459001R8711 – AE110-30-11 125V DC Contactor

MPN: 1SFL459001R8711 · Brand: ABB

Price on request

Discontinued by ABB — we can still source the original 1SFL459001R8711 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ABB A Contactors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	2.04 kg
UPC / EAN	7320500191323

Shipping & availability

Can I still buy the 1SFL459001R8711 now that it is discontinued?

Yes. ABB has discontinued the 1SFL459001R8711, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 1SFL459001R8711 be shipped?

1SFL459001R8711 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1SFL459001R8711 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1SFL459001R8711 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SFL459001R8711, subject to availability and destination.

A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V.Operated with control voltage, versions from 12 to 250VDC

Lifecycle: ABB lists this product as inactive (discontinued). PartnerPLC sources discontinued ABB parts — request a quote for availability, or ask us about the current ABB successor.

Specifications

General

Order code (ABB product ID)	1SFL459001R8711
Type	AE110-30-11 125V DC
Lifecycle	Discontinued (inactive at ABB)

Ordering

Minimum Order Quantity	1 piece
Customs Tariff Number	85364900
Replacement Product ID (NEW)	1SFL427001R1311

Dimensions

Product Net Width	114 mm
Product Net Depth / Length	123.5 mm
Product Net Height	148 mm
Product Net Weight	2.04 kg

Technical

Number of Main Contacts NO	3
Number of Main Contacts NC	0
Number of Auxiliary Contacts NO	1
Number of Auxiliary Contacts NC	1
Number of Poles	3P
Rated Operational Voltage	Main Circuit 1000 V
Rated Frequency (f)	Main Circuit 50 / 60 Hz
Conventional Free-air Thermal Current (I<sub>th</sub>)	acc. to IEC 60947-4-1, Open Contactors Θ = 40 °C 160 A
Rated Operational Current AC-1 (I<sub>e</sub>)	(690 V) 40 °C 160 A, (690 V) 55 °C 145 A, (690 V) 70 °C 130 A
Rated Operational Current AC-3 (I<sub>e</sub>)	(415 V) 55 °C 110 A, (440 V) 55 °C 100 A, (500 V) 55 °C 100 A, (690 V) 55 °C 82 A, (1000 V) 55 °C 30 A, (380 / 400 V) 55 °C 110 A, (220 / 230 / 240 V) 55 °C 110
Rated Operational Power AC-3 (P<sub>e</sub>)	(415 V) 59 kW, (440 V) 59 kW, (500 V) 59 kW, (690 V) 75 kW, (1000 V) 40 kW, (380 / 400 V) 55 kW, (220 / 230 / 240 V) 30 kW
Rated Operational Power AC-6b (P<sub>e</sub>)	(500 / 550 V), 40 °C, 50 / 60 Hz 83 kvar, (500 / 550 V) 55 °C, 50 / 60 Hz 83 kvar, (500 / 550 V) 70 °C, 50 / 60 Hz 78 kvar, (690 V) 40 °C, 50 / 60 Hz 90 kvar, (690 V) 55 °C, 50 / 60 Hz 90 kvar, (690 V) 70 °C, 50 / 60 Hz 85 kvar
Rated Breaking Capacity AC-3	8 x Ie AC-3
Rated Making Capacity AC-3	10 x Ie AC-3
Short-Circuit Protective Devices	gG Type Fuses 200 A
Rated Short-time Withstand Current Low Voltage (I<sub>cw</sub>)	at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 800 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 15 min 175 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 1 min 350 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 1 s 1320 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 30 s 500 A
Rated Insulation Voltage (U<sub>i</sub>)	acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V, acc. to UL/CSA 600 V
Rated Impulse Withstand Voltage (U<sub>imp</sub>)	8 kV
Maximum Electrical Switching Frequency	(AC-1) 300 cycles per hour, (AC-2 / AC-4) 150 cycles per hour, (AC-3) 300 cycles per hour
Mechanical Durability	5 million
Maximum Mechanical Switching Frequency	1200 cycles per hour
Coil Operating Limits	(acc. to IEC 60947-4-1) Uc (at θ ≤ 70 °C)
Rated Control Circuit Voltage (U<sub>c</sub>)	DC Operation 125 V
Coil Consumption	Holding at Max. Rated Control Circuit Voltage 50 Hz 2.4 W, Holding at Max. Rated Control Circuit Voltage DC 2.4 W, Pull-in at Max. Rated Control Circuit Voltage DC 400 W
Power Loss	at Rated Operating Conditions per Pole 3.8 W
Operate Time	Between Coil De-energization and NC Contact Closing 15 ... 20 ms, Between Coil De-energization and NO Contact Opening 18 ... 23 ms, Between Coil Energization and NC Contact Opening 12 ... 22 ms, Between Coil Energization and NO Contact Closing 15 ... 25 ms
Degree of Protection	acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP40
Connecting Terminals (delivered in open position) Main Poles	M8 hexagon socket screw with single connector
Terminal Type	Cable Clamp
Product Name	Block Contactor

Technical UL/CSA

Horsepower Rating UL/CSA	(200 V AC) Three Phase 30 hp, (208 V AC) Three Phase 30 hp, (220 ... 240 V AC) Three Phase 40, (440 ... 480 V AC) Three Phase 75 hp, (550 ... 600 V AC) Three Phase 100 hp
Full Load Amps Motor Use	(440 ... 480 V AC) Three Phase 96 A, (550 ... 600 V AC) Three Phase 99 A

Environmental

Ambient Air Temperature	Close to Contactor Fitted with Thermal O/L Relay (0.85 ... 1.1 Uc) -25 ... 55 °C, Close to Contactor without Thermal O/L Relay (0.85 ... 1.1 Uc) -25 ... 70 °C, Close to Contactor for Storage -40 ... 70 °C
Maximum Operating Altitude Permissible	Without Derating 3000 m

Material Compliance

RoHS Information	Following EU Directive 2002/95/EC August 18, 2005 and amendment
WEEE B2C / B2B	Business To Business
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards

Object Classification Code	Q
ETIM 7	EC000066 - Power contactor, AC switching
ETIM 8	EC000066 - Power contactor, AC switching
ETIM 9	EC000066 - Power contactor, AC switching
eClass	V11.0 : 27371003
UNSPSC	39121529
