ABB 1SFL431074R9002 – AX95J-30-11*220-230V 50Hz/230-240V60Hz

MPN: 1SFL431074R9002 · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ABB AX Contactors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	1.9 kg
UPC / EAN	7320500511602

Shipping & availability

When can 1SFL431074R9002 be shipped?

1SFL431074R9002 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1SFL431074R9002 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1SFL431074R9002 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SFL431074R9002, subject to availability and destination.

AX95...AX115 contactors are mainly used for controlling 3-phase motors and power circuits up to 690 V AC. These contactors are of the block type design with: – 3 main poles – control circuit: AC operated – add-on auxiliary contact blocks (optional) for side mounting and a wide range of accessories.

Specifications

General

Order code (ABB product ID)	1SFL431074R9002
Type	AX95J-30-11*220-230V 50Hz/230-240V60Hz
Lifecycle	Active (current ABB product)

Ordering

Minimum Order Quantity	1 piece
Customs Tariff Number	85364900

Dimensions

Product Net Width	102 mm
Product Net Depth / Length	123.5 mm
Product Net Height	148 mm
Product Net Weight	1.9 kg

Technical

Number of Main Contacts NO	3
Number of Main Contacts NC	0
Number of Auxiliary Contacts NO	1
Number of Auxiliary Contacts NC	1
Number of Poles	3P
Rated Operational Current AC-1 (I<sub>e</sub>)	(690 V) 40 °C 145 A, (690 V) 60 °C 135 A, (690 V) 70 °C 115 A
Rated Operational Current AC-3 (I<sub>e</sub>)	(415 V) 55 °C 96 A, (440 V) 55 °C 93 A, (500 V) 55 °C 80 A, (690 V) 55 °C 65 A, (380 / 400 V) 55 °C 96 A, (220 / 230 / 240 V) 55 °C 96 A
Rated Operational Power AC-3 (P<sub>e</sub>)	(380 / 400 V) 45 kW
Power Loss	at Rated Operating Conditions per Pole 2.7 W
Product Name	Block Contactor

Environmental

Maximum Operating Altitude Permissible

Without Derating 3000 m

Material Compliance

RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
WEEE B2C / B2B	Business To Business
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards

Object Classification Code	Q
ETIM 7	EC000066 - Power contactor, AC switching
ETIM 8	EC000066 - Power contactor, AC switching
ETIM 9	EC000066 - Power contactor, AC switching
eClass	V11.0 : 27371003
UNSPSC	39121529
IDEA Granular Category Code (IGCC)	4755 >> Contactors

Downloads & documentation

Official documents from ABB, downloaded directly from the manufacturer.

Data sheets & manuals

Data Sheet, Technical Information (1SBC100214C0202)
Instructions and Manuals (9AKK107492A7060)

CAD & dimension drawings

CAD Dimensional Drawing (2CDC001079B0201)

Certificates (5)

REACH Declaration (2CMT2021-006202)
RoHS Declaration (2CMT2021-006277)
CQC Certificate (CQC2013010304646592)
Declaration of Conformity - CCC (2020980304001063)
Declaration of Conformity - CE (2CMT2015-005443)
