ABB 1SBN050100R1001 – RC5-1/133 Surge Suppressor
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ABB Block Contactors |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 0.012 kg |
| Country of origin | India |
| UPC / EAN | 3471522121257 |
Shipping & availability
When can 1SBN050100R1001 be shipped?
1SBN050100R1001 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1SBN050100R1001 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1SBN050100R1001 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SBN050100R1001, subject to availability and destination.
RC5-1/133 is a RC type surge suppressor designed to reduce the maximum overvoltage peak value and to limit or even completely eliminate the high pre-damping voltage frequencies, when used with an AC operated conventional contactor for a rated control circuit voltage between 50 ...133 V AC 50/60Hz.
The operation of inductive circuits causes overvoltages, in particular on opening of the contactor coil. The electromagnetic energy stored in the coil during contactor closing is restored on opening in the form of surges, the slope and amplitude of which may rise to several kilovolts. A number of drawbacks are observed ranging from interference on the electronic devices to breakdown of insulators and even destruction of certain sensitive components.
Advantages:
- the surge suppressor is clipped onto the top or side part in regards with the contactor or contactor relay base design without change in device overall dimensions.
- very fast clipping: attenuation of steep fronts and thus of high frequencies. No operating delays.
Specifications
General
| Order code (ABB product ID) | 1SBN050100R1001 |
| Type | RC5-1/133 |
| Lifecycle | Active (current ABB product) |
| Country of origin | India |
Ordering
| Minimum Order Quantity | 2 piece |
| Customs Tariff Number | 85363030 |
Dimensions
| Product Net Width | 30.25 mm |
| Product Net Depth / Length | 32.4 mm |
| Product Net Height | 10.5 mm |
| Product Net Weight | 0.012 kg |
Technical
| Rated Frequency (f) | Control Circuit 50 / 60 Hz |
| Rated Control Circuit Voltage (U<sub>c</sub>) | 50 Hz / 60 Hz 50 ...133 V AC |
| Suitable For | AS09, AS12, AS16, NS22E, NS31E, NS40E, NS44E, NS53E, NS62E, NS71E, NS80E, VAS09, VAS12, VAS16, A9, A12, A16, A26, A30, A40, UA16, UA26, UA30, UA16RA, UA26RA, UA30RA, N22E, N31E, N40E, N44E, N53E, N62E, N71E, N80E, N33/11, N51/11, AX06, AX09, AX12, AX18, AX25, AX32, AX40 |
| Product Name | Surge Suppressor |
Environmental
| Ambient Air Temperature | Operation -20 ... +70 °C |
Material Compliance
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
External Classifications and Standards
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| eClass | V11.0 : 27371392 |
| UNSPSC | 39121610 |
| IDEA Granular Category Code (IGCC) | 4906 >> Surge suppressers |
| E-Number (Sweden) | 3228857 |
Downloads & documentation
Official documents from ABB, downloaded directly from the manufacturer.
Data sheets & manuals
| Data Sheet, Technical Information (1SBC100214C0202) | |
| Instructions and Manuals (1SBC101020M9701) |
CAD & dimension drawings
| CAD Dimensional Drawing (2CDC001079B0201) |
