ABB 1SBL361022R8011 – UAFC40-30-11-80 220-230V 50Hz 230-240V 60Hz Contactor

MPN: 1SBL361022R8011 · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ABB Block Contactors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	1.037 kg
UPC / EAN	3471525001181

Shipping & availability

When can 1SBL361022R8011 be shipped?

1SBL361022R8011 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1SBL361022R8011 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1SBL361022R8011 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SBL361022R8011, subject to availability and destination.

The UAFC40-30-11-80 is a 3 pole - 690 V IEC or 600 V UL capacitor switching contactor with 2 auxilieary contacts, controlling capacitors up to 40 KVR /400V AC-6b. The contactor can be used for installations in which the peak current up to 100 times nominal rms current

resistors and must be used without additional inductances. The contactor are AC - 220 ... 230 VLT 50Hz and 230 ... 240 VLT 60Hz controlled and can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories.

Specifications

General

Order code (ABB product ID)	1SBL361022R8011
Type	UAFC40-30-11-80
Lifecycle	Active (current ABB product)

Ordering

Minimum Order Quantity	1 piece
Customs Tariff Number	85364900

Dimensions

Product Net Width	67 mm
Product Net Depth / Length	111 mm
Product Net Height	119.5 mm
Product Net Weight	1.037 kg

Technical

Number of Main Contacts NO	3
Number of Main Contacts NC	0
Number of Auxiliary Contacts NO	1
Number of Auxiliary Contacts NC	1
Number of Poles	3P
Standards	IEC 60947-1 / 60947-4-1 and EN 60947-1 / 60947-4-1
Rated Operational Voltage	Auxiliary Circuit 690 V, Main Circuit 690 V
Rated Frequency (f)	Auxiliary Circuit 50 / 60 Hz, Control Circuit 50 / 60 Hz, Main Circuit 50 / 60 Hz
Rated Operational Current AC-15 (I<sub>e</sub>)	(500 V) 2 A, (690 V) 2 A, (24 / 127 V) 6 A, (220 / 240 V) 4 A, (380 / 400 V) 3 A
Rated Operational Current DC-13 (I<sub>e</sub>)	(24 V) 6 A / 144 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (125 V) 0.55 A / 69 W, (220 V) 0.27 A / 60 W, (250 V) 0.27 A / 68 W
Rated Operational Power AC-6b (P<sub>e</sub>)	(230 / 240 V) 40 °C, 50 / 60 Hz 23 kvar, (230 / 240 V) 60 °C, 50 / 60 Hz 19 kvar, (230 / 240 V) 70 °C, 50 / 60 Hz 18.5 kvar, (400 / 415 V) 40 °C, 50 / 60 Hz 40 kvar, (400 / 415 V) 70 °C, 50 / 60 Hz 32 kvar, (400 / 415 V) 60 °C, 50 / 60 Hz 33 kvar, (440 V) 40 °C, 50 / 60 Hz 40 kvar, (440 V) 60 °C, 50 / 60 Hz 36 kvar, (440 V) 70 °C, 50 / 60 Hz 35 kvar, (500 / 550 V), 40 °C, 50 / 60 Hz 40 kvar, (500 / 550 V) 60 °C, 50 / 60 Hz 40 kvar, (500 / 550 V) 70 °C, 50 / 60 Hz 40 kvar, (690 V) 40 °C, 50 / 60 Hz 55 kvar, (690 V) 60 °C, 50 / 60 Hz 55 kvar, (690 V) 70 °C, 50 / 60 Hz 52 kvar
Short-Circuit Protective Devices	Auxiliary Circuit - gG Type Fuses 10 A, gG Type Fuses 1.5 ... 1.8 In A
Maximum Breaking Capacity	cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 950 A, cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 600 A
Rated Insulation Voltage (U<sub>i</sub>)	acc. to IEC 60947-4-1 690 V, acc. to IEC 60947-5-1 690 V, acc. to UL/CSA 600 V
Rated Impulse Withstand Voltage (U<sub>imp</sub>)	6 kV
Maximum Electrical Switching Frequency	240 cycles per hour
Mechanical Durability	10 million
Maximum Mechanical Switching Frequency	3600 cycles per hour
Coil Operating Limits	(acc. to IEC 60947-4-1) 0.85 x Uc Min. ... 1.1 x Uc Max. (at θ ≤ 60 °C)
Rated Control Circuit Voltage (U<sub>c</sub>)	50 Hz 220 ... 230 V, 50 Hz 220 ... 230 V, 60 Hz 230 ... 240 V
Coil Consumption	Average Holding Value 50 / 60 Hz 20 V·A, Average Pull-in Value 50 Hz 150 V·A, Average Pull-in Value 60 Hz 151 V·A
Power Loss	at Rated Operating Conditions per Pole 2.1 W
Operate Time	Between Coil De-energization and NC Contact Closing 6 ... 19 ms, Between Coil De-energization and NO Contact Opening 4 ... 14 ms, Between Coil Energization and NC Contact Opening 3 ... 16 ms, Between Coil Energization and NO Contact Closing 7 ... 21 ms
Mounting on DIN Rail	TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Mounting by Screws (not supplied)	2 x M4 or 2 x M6 Screws Placed Diagonally
Connecting Capacity Main Circuit	Flexible with Ferrule 1/2x 4 ... 35 mm², Flexible with Insulated Ferrule 1/2x 4 ... 35 mm²
Connecting Capacity Auxiliary Circuit	Flexible with Ferrule 1/2x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.75 ... 1.5 mm², Rigid Cable 1/2x 1 ... 2.5 mm², Rigid Solid 1/2x 1 ... 2.5 mm², Rigid Stranded 1/2x 1 ... 2.5 mm²
Connecting Capacity Control Circuit	Rigid Solid 1/2x 1 ... 2.5 mm², Rigid Stranded 1/2x 1 ... 2.5 mm²
Wire Stripping Length	Control Circuit 10 mm
Degree of Protection	acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20, acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20, acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP10
Power Rating Capacitor Switching	(240 V AC) 20 kvar, (480 V AC) 40 kvar, (600 V AC) 50 kvar
Recommended Screw Driver	Pozidriv PZ
Tightening Torque	Auxiliary Circuit 1.2 N·m, Control Circuit 1.2 N·m, Main Circuit 4 N·m
Terminal Type	Screw Terminals
Product Name	Block Contactor

Technical UL/CSA

Maximum Operating Voltage UL/CSA	Main Circuit 600 V
Connecting Capacity Main Circuit UL/CSA	1/2x 17-2 AWG, Rigid Solid 1/2x 10-2 AWG, Rigid Stranded 1/2x 10-2 AWG
Connecting Capacity Auxiliary Circuit UL/CSA	Rigid Solid 1/2x 18-14 AWG, Rigid Stranded 1/2x 18-14 AWG
Connecting Capacity Control Circuit UL/CSA	Rigid Solid 1/2x 18-14 AWG, Rigid Stranded 1/2x 18-14 AWG
Tightening Torque UL/CSA	Auxiliary Circuit 11 in·lb, Control Circuit 11 in·lb, Main Circuit 35 in·lb

Environmental

Ambient Air Temperature	Close to Contactor for Storage -60 ... +80 °C, Near Contactor for Operation in Free Air (Uc) -40 ... 70 °C
Climatic Withstand	Category B according to IEC 60947-1 Annex Q
Maximum Operating Altitude Permissible	Without Derating 3000 m
Pollution Degree	3

Material Compliance

RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
WEEE B2C / B2B	Business To Business
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards

Object Classification Code	Q
ETIM 7	EC001079 - Capacitor contactor
ETIM 8	EC001079 - Capacitor contactor
ETIM 9	EC001079 - Capacitor contactor
eClass	V11.0 : 27371006
UNSPSC	39121529
IDEA Granular Category Code (IGCC)	4756 >> Capacitor magnet contactor
