Home / ABB / AC500-XC CPUs / ABB 1SAP350100R0271

ABB

ABB 1SAP350100R0271

PM591-ETH-XC

MPN: 1SAP350100R0271
Category: AC500-XC CPUs

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 1SAP350100R0271?

PM591-ETH-XC: AC500 Processor module. Memory 4MB. Interfaces: Ethernet, 2x RS232/485, FBP. Display. eXtreme Conditions

Specifications

Ordering

CN8	85389091
Invoice Description	Processor module. Memory 4MB. Interfaces: Ethernet, 2x RS232/485, FBP. Display (PM591-ETH-XC)
Made To Order	No
Minimum Order Quantity	1 piece
Order Multiple	1 piece
Selling Unit of Measure	piece

Dimensions

Product Net Weight	0.139 kg kg
Product Net Depth / Length	62 mm mm
Product Net Height	76 mm mm
Product Net Width	67.5 mm mm
Gross Weight	0.163 kg kg
Package Level 1 Depth / Length	84 mm mm
Package Level 1 Height	72 mm mm
Package Level 1 Width	71 mm mm
Package Level 1 Units	1 carton

Certificates and Declarations

Declaration of Conformity - CE	3ADR980140
REACH Date	20241206
REACH Declaration	3ADR980139
REACH Information	True - contains substances > 0.1 mass percentage
SCIP	8817cf42-809a-4350-b3e4-77cd606451d7 Germany
RoHS Declaration	3ADR980140
RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Technical

Function	Memory 4MB. Interfaces: Ethernet, 2x RS232/485, FBP. Display
Number of Hardware Interfaces	Industrial Ethernet 1, Other 2, Parallel 0, RS-232 0, RS-422 0, RS-485 0, Serial TTY 0, USB 0, Wireless 0
Memory Size	9728 kB
Memory Type User Data	RAM
Controller Processing Time	0.000002 ms
Degree of Protection	IP20
Rated Voltage (Ur)	24 V DC V
Supply Voltage	20.4 … 28.8 V DC V
Ambient Air Temperature	Operation -30...+70 °C, Storage -40...+85 °C

Additional Information

Product Main Type	PM591
Product Name	Distributed Automation PLCs

External Classifications and Standards

eClass	27-24-22-07
ETIM 8	EC000236 - PLC CPU-module
ETIM 9	EC000236 - PLC CPU-module
ETIM 10	EC000236 - PLC CPU-module
UNSPSC	32151705

Environmental

WEEE B2C / B2B	Business To Business
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm) cm

1SAP350100R0271: frequently asked questions

When can 1SAP350100R0271 be shipped?

1SAP350100R0271 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1SAP350100R0271 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1SAP350100R0271 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SAP350100R0271, subject to availability and destination.
