Directional on/off valve Parts
Compare Directional on/off valve
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product family | Max. flow [l/min] | Seals | Weight [kg] |
|---|---|---|---|---|
| R900902112 | WE6../E | 80.0 | NBR | 2.08 |
| R901028603 | WE6../E | 80.0 | NBR | 2 |
| R901309285 | WE 6…XN | 50.0 | NBR | 2.29 |
| R901417083 | WE6../E | 80.0 | NBR | 1.98 |
| R901241232 | WE6../E | 80.0 | NBR | 2 |
| R901224782 | WE6../E | 80.0 | NBR | 2.56 |
| R901346939 | WE6../E | 80.0 | NBR | 2.58 |
| R901188077 | WE6../E | 80.0 | NBR | 3.28 |
| R901492696 | WE6../E | 50.0 | NBR | 3.25 |
| R901281220 | WE6../E | 80.0 | NBR | 3.18 |
| R901307909 | WE6../E | 80.0 | NBR | 1.98 |
| R901453308 | WE6../E | 50.0 | NBR | 2.06 |
| R900932807 | WE6../E | 80.0 | NBR | 1.96 |
| R901503451 | WE6../E | 80.0 | NBR | 2 |
| R901097034 | WE6../E | 80.0 | FKM | 1.96 |
| R900969451 | WE6../E | 80.0 | NBR | 1.97 |
| R900929366 | WE6../E | 80.0 | FKM | 1.98 |
| R901199941 | WE6../E | 80.0 | FKM | 1.96 |
| R901133069 | WE6../E | 80.0 | FKM | 1.96 |
| R901193595 | WE6../E | 80.0 | NBR | 1.96 |
| R900974845 | WE6../E | 80.0 | FKM | 1.96 |
| R900932661 | WE6../E | 80.0 | NBR | 1.98 |
| R901293068 | WE6../E | 80.0 | FKM | 1.96 |
| R900964940 | WE6../E | 80.0 | NBR | 1.96 |
Common to all listed parts
| Connection diagram | ISO 4401-03-02-0-05 |
| Operating pressure, max. [bar] | 350.0 |
| Spool symbol | Symbol H |
| Size | 6 |
| Type of actuation | with solenoid actuation |
| Number of ports | 4 |
| Number of switching positions | 3 |
| Supply voltage | 24 VDC |
