SCALANCE XRM-300 rack mainstream Parts
Compare SCALANCE XRM-300 rack mainstream
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | global warming potential [CO2 eq] — total | global warming potential [CO2 eq] — during manufacturing | global warming potential [CO2 eq] — during operation | global warming potential [CO2 eq] — after end of life | MTBF |
|---|---|---|---|---|---|
| 6GK5334-3TS01-4AR3 | 1125.275 kg | 207 kg | 915 kg | 0.925 kg | 10.6 a |
| 6GK5334-3TS01-3AR3 | 1274.81 kg | 225.96 kg | 1048 kg | 0.85 kg | 8.6 a |
| 6GK5334-3TS01-2AR3 | 2101.59 kg | 132 kg | 1969 kg | 0.59 kg | 13.2 a |
| 6GK5334-5TS01-4AR3 | 2882 kg | 173 kg | 2708 kg | 1 kg | 12.7 a |
| 6GK5334-5TS01-3AR3 | 2882 kg | 173 kg | 2708 kg | 1 kg | 9.9 a |
| 6GK5334-5TS01-2AR3 | 2239.67 kg | 138 kg | 2101 kg | 0.67 kg | 16.7 a |
Common to all listed parts
| product type designation | XRM334 |
| number of 1000/2500/5000/10000 Mbps RJ45 ports / with securing collar | 2 |
| number of electrical connections — for SFP+ | 8; 1000 Mbps and 10000 Mbps SFP usable |
| number of electrical connections — for operator console | 1 |
| number of electrical connections — for signaling contact | 1 |
| type of electrical connection — for operator console | USB (2.0 type B, USB-to-serial adapter) |
| type of electrical connection — for signaling contact | 2-pole terminal block |
| design of the removable storage — CLP | Yes |
