AL8066 Parts
Compare AL8066
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Max. speed | Continuous force | Peak current | Continuous current | Force constant |
|---|---|---|---|---|---|
| AL8066-1Jyz-0000 | 3 m/s | 1200 N | 18 A | 6.4 A | 186 N/A |
| AL8066-1Nyz-0000 | 6 m/s | 1200 N | 42 A | 15 A | 79 N/A |
| AL8066-0Jyz-0000 | 3 m/s | 1140 N | 18 A | 6.1 A | 187 N/A |
Common to all listed parts
| Motor type | 3-phase synchronous linear servomotors |
| Nominal voltage | 100…480 V AC |
| Peak force | 2700 N |
| Connection technology | M23 speedtec® plug |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus |
| Protection rating | IP64 |
| Overall width | W6 (130 mm) |
