AM8332 Parts
Compare AM8332
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Rated torque | Rated speed | Rated power | Standstill current | Peak current |
|---|---|---|---|---|---|
| AM8332-wJyz | 5.40 Nm | 4000 min-1 | 2.26 kW | 6.80 A | 17.2 A |
| AM8332-wLyz | 4.69 Nm | 8500 min-1 | 4.17 kW | 10.4 A | 29.5 A |
| AM8332-wFyz | 5.30 Nm | 2200 min-1 | 1.22 kW | 3.80 A | 9.6 A |
Common to all listed parts
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100…480 V AC |
| Peak torque | 11.7 Nm |
| Rotor moment of inertia | 0.847 kgcm² |
| Cooling | water cooling |
| Connection technology | M23 speedtec® plug |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus in preparation |
